Wir haben am 04.11.2022 unser Dodekaeder beim Paderborner Martinslauf aufgebaut und den ein oder anderen neugierigen Blick auf uns gezogen:
Der Aufbau diente gleichzeitig dazu, unsere Kooperation des Reparaturtreffs mit dem FreiWerk Paderborn e.V. zu bewerben. Wir bedanken uns herzlich bei Anna und Lena vom FreiWerk für die Mithilfe!
Am Samstag, den 27. August lädt der C3PB ab 15 Uhr in seinen Vereinsräumen in der Westernmauer 12-16 zum Tag des offenen Hackerspace ein. Unser Eingang ist zur Zeit hinter der Baustellentreppe versteckt - folge dem weißen Kaninchen!
Als einer von zahlreichen lokalen Vertretern des Chaos Computer Clubs freuen wir uns nach mehr als zwei Jahren pandemiebedingter Schließung auf Besuch. Wir freuen uns auf zahlreiche Gäste denen wir unseren Verein und unsere Projekte vorstellen dürfen.
Hackerspaces sind offene Orte für den kreativen Umgang mit Technik. Dort stehen nicht nur Werkzeuge wie 3D-Drucker und Elektroniklabore bereit, sondern sie bieten auch den Raum, in dem sich Hacker, Maker und Bastler treffen, um sich auszutauschen und gemeinsam an Projekten zu arbeiten.
Bei Rückfragen könnte ihr uns unter mail@c3pb.de erreichen.
Gemeinsam mit dem Freiwerk-Paderborn veranstalten wir am 10. April um 13 Uhr einen Einsteiger-Lötworkshop. Dazu eingeladen sind alle, die gerne den Einstieg ins Löten und die angewandte Elektrotechnik wagen wollen. Es sind keinerlei Vorkenntnisse nötig.
Der Wörkshop findet in unseren Räumen in der Westernmauer 12-16 statt.
In dem Workshop lötest du eine Platine namens “Blinkenrocket” [0] und lernst dabei den Umgang mit dem Lötkolben, Lötzinn und den Bauteilen der Platine.
Die Anmeldung erfolgt über die Website des Freiwerks [1], es gelten die dort aufgeführten Datenschutzbestimmungen.
[1] https://freiwerk-paderborn.de/events/loeten-fuer-einsteiger/
Der c3pb e.V. veranstaltet am 27. November einen Einsteiger-Lötworkshop. Dazu eingeladen sind alle, die gerne den Einstieg ins Löten und die angewandte Elektrotechnik wagen wollen. Es sind keinerlei Vorkenntnisse nötig.
In dem Workshop lötet ihr eine Platine Namens “Blinkenrocket” [0] und lernt dabei den Umgang mit dem Lötkolben, Lötzinn und den Bauteilen der Platine.
Der Workshop ist umsonst, aber wir freuen uns natürlich gern über eine Spende.
Der Workshop beginnt um 12 Uhr im subraum an der Westernmauer 12-16, 33106 Paderborn, es gibt 10 Plätze, die nach dem first-come-first-serve-Prinzip vergeben werden, bitte meldet euch per Email an mail@c3pb.de verbindlich an.
Denkt bei der Teilnahme bitte an eure Maske und den 3G-Nachweis (Geimpft, Genesen, Getestet).
Update 22.11.: Leider muss der Wörkshop verschoben werden. Interessenten können sich dennoch weiter per Mail melden und bekommen dann sobald der neue Termin feststeht eine Benachrichtigung
I just wanted to double-check the voltage before plugging the power supply connector into my board and then I was confused because it read as zero volts. Of course, I had still plugged the test leads into the current input and of course that killed the fuse. My other multimeter (an older Mastech) complains very loudly when the leads are plugged into the wrong holes but this time I was using the Fluke. Fuses can’t be too expensive, can they? Well, they can. That’s more than 10€ with shipping and other sources aren’t much cheaper.
On Ebay, I saw cheap alternatives with shipping from China and I was curious. I ordered 10 pieces on AliExpress for 15€, which is only slightly more than what I would have paid for one original. I had some previous experience with polyfuses from AliExpress: They were rated for 2A/6V but they work “very well” for 15A (until I stopped the test because the test leads were getting hot - I hadn’t planned to test with such high currents). Thus, the Ali fuses will certainly not go into my multimeter without a thorough test!
Original fuses are labelled with “Bussmann”. The ones from Ali are similar but they are labelled “Bassmann” so certainly not original parts but that was to be expected. Fun fact: Some images on Ebay are blurred in exactly that place.
Let’s start with a quick sanity check: All of them have between 0.5 and 0.7 Ohms of resistance. Looking good. That’s not very accurate with a two lead measurement, of course. I get 0.3 to 0.4 Ohms when I hold both leads to one cap of the fuse so we may have a huge error here.
I’m using a DPM8608 power supply and a Mooshimeter. I have also connected a Red Pitaya oscilloscope with a Hantek CC-65 current probe because I will use that for later tests. The setup is a bit chaotic because there isn’t much free space on my desk. Sorry for that!
The Mooshimeter can do graphs. Very useful if the fuse blows while I’m not paying attention. This graph is from the Android app but it is also supported by Sigrok:
I have tested with 410 mA so slightly over the rated current (or so I thought, see below). The fuse survived for an hour before I got bored and moved on to the next test. So far, so good.
The Mooshimeter is connected to the same aligator clamps as the power supply so its voltage measurement will include the voltage drop of the clamps. If we want to calculate the resistance of the fuse, we will need the voltage directly at the fuse. The fuse has huge metal caps so I can use the Fluke to measure the voltage between those caps. The trick is that there isn’t any current going into the Fluke (well, almost none) so the contact resistance to the Fluke doesn’t influence the measurement. This is often called 4-wire or Kelvin measurement.
We get 0.171 V on the Mooshimeter and the Fluke agrees when connected to the alligator clamps. We get 0.144 V between the caps of the fuse. Thus, our estimate of the resistance would be 20% too high if we didn’t use 4-wire measurement. The resulting resistance is R = U/I = 0.144V/0.409A = 0.352 Ohms. I guess this is ok. Unfortunately, I don’t see any specs for resistance in the Bussmann datasheet and the description on AliExpress is very sparse on specifications - as usual. Thus, we have nothing to compare this to. I guess, the resistance could change over time (e.g. if the fuse is slightly damaged by the current or heats up significantly) but it is still the same after an hour.
Post scriptum: The fuse is for the 400 mA range of the multimeter but it is rated for 440 mA so I have tested it below its rated current.
Test setup: Set the power supply to 4 A (10 times the rated current of the fuse), set the oscilloscope to trigger on a rising edge of the current, enable the power supply.
The input is connected to a Hantek CC-65 current probe with 1mV/10mA. Thus, 50 mV/div is 0.5A/div. There is a small offset - I guess that I should calibrate the Red Pitaya again. The vertical cursors are at 0 mA and 400 mA, the trigger level is between them.
This is the result:
That’s weird: I had expected the current to rise until the fuse blows and then quickly fall to zero. That’s not what happens. Why?
The first part is quite simple: Many power supplies use a relay to enable/disable the output. The DPM8608 simply disables the voltage regulator. That way, we don’t have any contact bouncing but the current rises more slowly. That’s not ideal for our test but good for other uses of that power supply. Of course, I could plug the banana connector instead if I prefer fast rise times with bouncing.
Let’s turn on the power supply into a short circuit without the fuse:
This also has a spike at the beginning and then rises more slowly. That seems to be the closed-loop control behavior of the power supply when enabled into a short. After 140 ms, we can see the behavior when the power supply is disabled. This looks like discharging a capacitor and I assume it is exactly that.
First part solved. What about the second part? Why does the current start to fall after 40 ms?
Some friends at the Hackerspace helped me with that. Here is what I hadn’t considered: The fuse blows by melting so the wire inside will become very hot. We usually ignore that resistance depends on temperature but we shouldn’t do that in this case. I had set the voltage limit to 5V because “that’s plenty”. Well, it isn’t! The current starts to fall at 40 ms because we run into the voltage limit before the fuse blows.
Here is my second try - this time with a voltage limit of 2V and we can see the voltage, as well:
We can see that the current starts to fall as soon as the voltage reaches 2V. The fuse did blow but only after the measurement interval so we don’t see this in the graph. D’oh.
Let’s assume that the wire is made of copper. Wikipedia says that copper has a melting point of 1084.62 °C and a temperature coefficient of alpha=3.93*10^−3 1/K. Thus, the resistance at the melting point will be: R_Tm = R_25*(1+alpha*(T_m - 25 °C) = 0.352 Ohm * (1+3.93e-3*(1084.62-25) = 1.82 Ohm. With that, we would have this current at the melting point: 5V / 1.82 Ohm = 2.75 A. The actual current is more like 1.5 A so I assume we have a material with a higher temperature coefficient and/ or melting point.
So, does the fuse pass or fail? Let’s have a look at the datasheet of the Bussmann fuse. Page 2 has a diagram with the time until the fuse blows for different currents. You can see that this can take minutes if the current is small enough. For the 4 A test, our fuse blew after 60 ms with an average curent of somewhere between 2.5 and 3 A. The diagram says, it should blow after 60 ms (0.06 sec) for a current that is slightly below 2 A. Thus, we are off by 25% to 50%. We had more current than that so our fuse is slower. We can also go in the other direction: 2.5A is below the chart so it should blow in less than 10 ms. It took 6 times as long! However, the curve is very steep so large differences in time are to be expected. EEVBlog has a video about this and they also find large variance in the times. They also explain how to read the chart in the datasheet.
For the second test, the current was above 2.4 A for 50 ms. This should blow the fuse according to the datasheet. This means that this fuse needs at least 20% more current than indicated by the datasheet. In addition, the current was above 1 A for most of the 200 ms. What does the datasheet say about that? Well, 1A is off the chart in the other direction. The fuse should survive this for quite a long time. However, it did blow and that’s ok because it was pre-heated by the 2.4 A. The curves in the datasheet only apply at room temperature.
With only two tries, there are very large error bars on our numbers and we don’t know how much variance there is for the original fuses (and whether the diagram shows the average or maximum time). Still, we can conclude that the “Bassmann” fuses blow at a higher current but probably not more than two times as much.
The fuses are different from the original ones: They need more current or time to blow. Thus, there will be a bit more stress on the multimeter. On the one hand, the difference is relatively small so the multimeter is still protected. On the other hand, do you really want to risk damaging a 300€ multimeter to save 3€ on fuses? Maybe, maybe not.
But there is more: I have only tested small currents and voltages. The fuses are rated for 1 kV and 10 kA. That’s a lot! There will be arcing and the fuse has to exstinguish that. Do I trust them to protect my multimeter and myself for CAT-III measurements? Not without a test! Unfortunately, I don’t see how I can do a safe and controlled test for that.
In addition, we want the fuse to have a low resistance because this will add to the burden voltage of the multimeter. My Fluke has a resistance of 1.4 Ohms for the 400 mA range (including the fuse) so the 0.352 Ohms of the fuse are the smaller part of that. Just a wild guess: The manufacturer might have focussed on low resistance at the cost of a higher trip current because that’s what customers can test at no cost.
To conclude, I think we can use the fuses for low voltage applications. If you do, please be careful and warn anyone who borrows the multimeter! Keep in mind that I’m not an expert on this (far from it!) so draw your own conclusions and whatever you decide is your responsibility not mine.
We know that the wire inside the fuses melts at 5V / 1.5A = 3.33 Ohm. Can we use that to determine what material it is made of? Not quite because the resistance at the melting point depends on the melting temperature as well as the temperature coefficient (i.e. how much resistance changes with temperature). We need more information to solve for two unknowns.
The wire inside the fuse will be warmer than the outside of the fuse if we send some current through it. We don’t really know how much warmer it will be because that depends on how much energy is needed to heat up the material and how well the energy can dissipate to the outside of the fuse by thermal conduction. However, the fuse will get into a steady state if we keep power dissipation and ambient temperature constant: The wire will heat up until the energy that is conducted away is equal to the energy that we add. If we raise the ambient temperature, the temperature difference between wire and ambient should remain constant so the wire should heat up by the same amount as the ambient temperature.
We need to accurately measure the resistance so we need 4-wire measurement. We can do it in the same way as yesterday:
This will work but there is a better way. Enter: Kelvin clamps.
The jaws are isolated so we have two independent contacts for each clamp. Each clamp has one wire for the power supply and one for the voltmeter. I’m so glad that I have these around from another project.
Let’s do some measurements:
Here is what this looks like:
And here are the results:
# Columns:
# - Fuse Number
# - Temperature [C] (ambient, OW18B)
# - Current [A] (Mooshimeter)
# - Voltage [V] (Fluke 177)
data = """fuse_number temperature current voltage
3 25 0.399 0.137
4 25 0.399 0.134
5 25 0.399 0.136
6 25 0.399 0.137
7 25 0.399 0.138
8 25 0.399 0.1375
9 25 0.399 0.131
3 25 0.100 0.031
4 25 0.100 0.031
5 25 0.100 0.031
6 26 0.100 0.033
7 26 0.100 0.032
8 26 0.100 0.031
9 26 0.100 0.0315
3 36 0.400 0.140
4 37 0.400 0.137
4 39 0.400 0.138
5 41 0.400 0.140
5 43 0.400 0.141
6 43 0.400 0.142
6 46 0.400 0.143
7 47 0.401 0.144
7 49 0.400 0.145
8 45 0.401 0.1445
8 47 0.401 0.145
9 50 0.400 0.140
9 52 0.401 0.141
"""
class NumMinMax(object):
__slots__ = ("min", "max", "value")
def __init__(self, value, min, max):
self.min = min
self.max = max
self.value = value
@staticmethod
def with_error(value, error):
return NumMinMax(value, value-error, value+error)
def __repr__(self):
return "NumMinMax(%f, min=%f, max=%f)" % (self.value, self.min, self.max)
def __add__(self, b):
if not isinstance(b, NumMinMax):
b = NumMinMax(b, b, b)
return NumMinMax(self.value+b.value, self.min+b.min, self.max+b.max)
def __sub__(self, b):
if not isinstance(b, NumMinMax):
b = NumMinMax(b, b, b)
return NumMinMax(self.value-b.value, self.min-b.max, self.max-b.min)
def __mul__(self, b):
if not isinstance(b, NumMinMax):
b = NumMinMax(b, b, b)
return NumMinMax(self.value*b.value, self.min*b.min, self.max*b.max)
def __truediv__(self, b):
if not isinstance(b, NumMinMax):
b = NumMinMax(b, b, b)
return NumMinMax(self.value/b.value, self.min/b.max, self.max/b.min)
temperature_error = 2
current_error = 0.001
voltage_error = 0.001
import csv, io
fuses = {}
with io.StringIO(data) as f:
reader = csv.DictReader(f, dialect="excel-tab")
for row in reader:
fuse_number = int(row["fuse_number"])
del row["fuse_number"]
row["temperature"] = NumMinMax.with_error(float(row["temperature"]), temperature_error)
row["current"] = NumMinMax.with_error(float(row["current"]), current_error)
row["voltage"] = NumMinMax.with_error(float(row["voltage"]), voltage_error)
if fuse_number not in fuses:
fuses[fuse_number] = []
fuses[fuse_number].append(row)
#display(fuses)
print("num: %-7s %-7s %-7s [1/K]" % ("avg", "min", "max"))
all_alphas = []
for num, measurements in fuses.items():
m1 = None
alphas = []
for m2 in measurements:
if m2["current"].value < 0.2:
# ignore these for now because they have a different gradient from inside to outside
continue
if m1 is None:
m1 = m2
continue
r1 = m1["voltage"]/m1["current"]
r2 = m2["voltage"]/m2["current"]
Tdiff = m2["temperature"] - m1["temperature"]
# r2 = r1*(1+alpha*(T2-T1))
# <=> alpha = (r2/r1 - 1)/(T2-T1)
alpha = (r2/r1-1)/Tdiff
alphas.append(alpha)
all_alphas.append(alpha)
alpha_avg = sum(alpha.value for alpha in alphas) / len(alphas)
alpha_min = min(alpha.min for alpha in alphas)
alpha_max = max(alpha.max for alpha in alphas)
print("%d: %7.4f, %7.4f, %7.4f" % (num, alpha_avg, alpha_min, alpha_max))
alpha_avg = sum(alpha.value for alpha in all_alphas) / len(all_alphas)
alpha_min = min(alpha.min for alpha in all_alphas)
alpha_max = max(alpha.max for alpha in all_alphas)
print("total: %7.4f, %7.4f, %7.4f" % (alpha_avg, alpha_min, alpha_max))
# Prefer the low-current measurement because it has less offset by internal heating.
R_25s = [m["voltage"]/m["current"] for num, measurements in fuses.items() for m in measurements if 24<=m["temperature"].value<=26 and m["current"].value < 0.2]
R_25 = sum(x.value for x in R_25s) / len(R_25s)
print("Resistance at 25 °C: %.4f" % R_25)
U_melt = 5
I_melt = 1.5
R_melt = U_melt / I_melt
# r2 = r1*(1+alpha*(T2-T1))
# <=> T2 = T1 + (r2/r1 - 1)/alpha
T_melt = (R_melt/R_25 - 1)/alpha_avg + 25
print("Rough estimation of melting temperature: %.1f °C" % T_melt)
T_melt_min = (R_melt/R_25 - 1)/alpha_max + 25
print("Rough estimation of melting temperature with alpha_max: %.1f °C" % T_melt_min)
num: avg min max [1/K]
3: 0.0018, -0.0000, 0.0056
4: 0.0018, -0.0000, 0.0050
5: 0.0018, 0.0004, 0.0039
6: 0.0019, 0.0006, 0.0039
7: 0.0019, 0.0007, 0.0034
8: 0.0023, 0.0011, 0.0041
9: 0.0026, 0.0016, 0.0042
total: 0.0020, -0.0000, 0.0056
Resistance at 25 °C: 0.3150
Rough estimation of melting temperature: 4758.2 °C
Rough estimation of melting temperature with alpha_max: 1729.0 °C
A melting point of almost 5000 °C. That can’t be right!
Let’s try something else: More temperature but less steady state:
The temperature will rise and fall very quickly with that setup so we don’t really have a steady state. My plan was to keep it at a constant temperature for some time but the hot air gun has significant variations in temperature so that won’t work. I heat it up and then take measurements while cooling down. That way, the multimeter will get an accurate reading of the case temperature, at least. The measurements are all over the place, though:
The blue dots are my measurements, the orange dots are for 0.347 Ohms at 25 °C and a thermal coefficient of 0.0028 1/K. This is not too far from my previous values but the melting point would be at 3100 °C. Still to high!
I know one problem with my measurements: I have to keep power dissipation constant but I do keep the current constant. Power dissipation will rise with resistance, which will increase internal temperature, which will increase the resistance. Thus, we will estimate an alpha that is too high but I think our alpha is actually too low.
I’m giving up for now. Those measurements cannot be right, I think. Do you have any ideas?
We can try something else: Wikipedia says that the wire is usually made of copper or silver.
R_25 = 0.310 # [Ohm], use measurement with low current for less inside heating
alpha_cu = 0.00393 # [1/K]
alpha_ag = 0.0038 # [1/K]
Tmelt_cu = 1085 # [°C]
Tmelt_ag = 962 # [°C]
Rmelt_cu = R_25 * (1 + alpha_cu*(Tmelt_cu - 25))
display(Rmelt_cu) # -> 1.60 Ohm
Rmelt_ag = R_25 * (1 + alpha_ag*(Tmelt_ag - 25))
display(Rmelt_ag) # -> 1.41 Ohm
Both of them don’t match the 3.33 Ohm that we have calculated earlier. Maybe my estimation of the resistance at the melting point isn’t right?
To be continued… as soon as I have more ideas for what I can try.
I still have seven fuses left. I don’t want to destroy them for no good reason and I might need some for my multimeter (not too many, I hope). Feel free to suggest additional tests.
I^2*t for my measurements.| Thema | Redner | Beschreibung |
|---|---|---|
